Epson EH-TW6700 User Manual

Contents
4
Setting Auto Iris ........................ 41
Setting Frame Interpolation............... 41
Setting the Image Processing Speed.........42
Adjusting the Color .................. 43
Adjusting the Color Temp................. 43
Adjusting the RGB (Offset and Gain).........43
Adjusting Hue, Saturation, and Brightness.....43
Adjusting the Gamma ...................45
Select and adjust the correction value . . . . . . 45
Adjust while viewing the image..........45
Adjust using the gamma adjustment graph . . 46
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 47
Saving a Memory ....................... 47
Loading, Deleting, and Renaming a Memory . . . 47
Useful Functions
Enjoying 3D Images .................. 49
Preparing to View 3D Images .............. 49
If the 3D image cannot be viewed .........49
Using 3D Glasses ....................... 50
Charging the 3D Glasses ................50
Pairing 3D Glasses ....................51
Wearing 3D Glasses ...................52
Reading the indicator on the 3D Glasses . . . . 52
Converting 2D Images to 3D ............... 52
Warnings Regarding Viewing 3D Images......53
Connecting with WirelessHD (EH-
TW6700W Only) ..................... 56
Installing the WirelessHD Transmitter........56
WirelessHD Transmitter part names ........ 57
WirelessHD Transmitter connection
example and signal flow ................ 58
Setting the WirelessHD Transmitter ........ 63
Projecting Images ...................... 63
WirelessHD Settings Menu................65
WirelessHD Transmission Range ............ 66
Operating the Remote Control............. 67
Remote Control Operating Range ...........67
Switching the Input and Output............ 67
Switching the target image .............. 68
Switching the image source .............69
Using the HDMI Link Function ........ 70
HDMI Link Function ..................... 70
HDMI Link Settings ...................... 70
Connecting ........................... 71
Playing Back Image Data (Slideshow) . . 72
Compatible Data ....................... 72
Starting a Slideshow ..................... 72
Settings for Slideshow ................... 72
Projecting Two Different Images Using
Picture in Picture .................... 74
Types of Screen that can be Displayed
Simultaneously ........................ 74
Projecting on a Picture in Picture ............ 74
Starting and exiting Picture in Picture......74
Changing the Picture in Picture settings . . . . 75
Using the Projector on a Network
Projecting Using Wired LAN (EH-
TW6800 Only) . . . . . . ................. 76
Selecting Wired Network Settings ...........76
Projecting Using Wireless LAN ........ 78
Selecting Wireless Network Settings Manually . . 78
Selecting the Computer's Wireless LAN Settings . 80
Selecting wireless network settings in
Windows ........................... 80
Selecting wireless network settings in OS X . . 80
Setting Up Wireless Network Security . . . . . . . . 81
Projecting in Epson iProjection .............81
Operating using a smartphone (remote
control function) .....................82
Configuration Menu
Configuration Menu Functions ........ 85
Configuration Menu Operations............85
Configuration Menu Table ................86
Image menu........................86
Signal menu ........................ 88
Settings menu ....................... 89
Extended menu ...................... 92
Downloaded from www.vandenborre.be

Epson EH-TW6700 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	2.95 - 4.8 m
Projection technology	3LCD
Contrast ratio (typical)	70000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Focus	Manual
Throw ratio	1.32 - 2.15:1
Zoom capability	Yes
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.51 - 1.99
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-24 - 24 %
Lamp power	250 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Color modes (2D)	Bright cinema, Cinema, Dynamic, Natural
Color modes (3D)	Cinema, Dynamic
Video processing	10 bit
Supported video modes	1080p
Analog signal format system	-
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Composite video in	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	32 dB
Country of origin	Philippines
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	364 W
Power consumption (PowerSave)	279 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Bundled software	EasyMP Multi PC Projection
Pallet width	800 mm
Pallet height	2030 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet (UK)	32 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	304 mm
Width	410 mm
Height	157 mm
Weight	6900 g
Package depth	495 mm
Package width	235 mm
Package height	475 mm
Package weight	9.105 g
