Epson EH-TW6700 User Manual

Contents
5
Network menu ....................... 95
Info menu .......................... 99
Reset menu ........................ 100
Troubleshooting
Problem Solving . . . ................. 101
Reading the Indicators .................. 101
Indicator status during an error/warning . . . 101
Indicator status during normal operation . . . 102
When the Indicators Provide No Help . . . . . . . 103
Check the problem ................... 103
Problems relating to images ............ 105
Noise problems ..................... 108
Problems when projection starts ......... 109
Problems with the remote control........109
Problems with the control panel . . . . . . . . . 109
Problems with 3D .................... 110
Problems with HDMI ................. 110
Bluetooth device problems ............. 111
Problems with WirelessHD (EH-TW6700W
only) ............................. 112
Network problems ................... 113
About Event ID ........................ 114
Maintenance
Maintenance . . . . . .................. 116
Cleaning the Parts ..................... 116
Cleaning the air filter ................. 116
Cleaning the main unit ................ 117
Cleaning the lens .................... 118
Cleaning the 3D Glasses ............... 118
Replacement Periods for Consumables...... 118
Air filter replacement period ............ 118
Lamp replacement period .............. 118
Replacing Consumables ................. 119
Replacing the air filter ................. 119
Replacing the lamp .................. 120
Resetting lamp hours ................. 121
Panel Alignment .................... 123
Color Uniformity (EH-TW6800 Only) . . 125
About PJLink (EH-TW6800 Only) . . . . . 127
Appendix
Optional Accessories and
Consumables ....................... 128
Optional Items ........................ 128
Consumables ......................... 128
Supported Resolutions .............. 129
Computer Signals (Analog RGB)........... 129
HDMI1/HDMI2 Input Signal ............... 129
MHL Input Signal ...................... 129
3D Input Signal HDMI ................... 130
3D Input Signal MHL .................... 130
WirelessHD Input Signal ................. 130
WirelessHD* Input Signal MHL ............. 130
Specifications ...................... 132
EH-TW6800/EH-TW6300 ................. 132
EH-TW6700W/EH-TW6700 ............... 133
Appearance ........................ 136
List of Safety Symbols ............... 137
Maximum radio-frequency power transmitted . 139
Glossary ........................... 140
General Notes ...................... 141
General Notice ........................ 142
Downloaded from www.vandenborre.be

Epson EH-TW6700 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	2.95 - 4.8 m
Projection technology	3LCD
Contrast ratio (typical)	70000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-30 - 30 °
Focus	Manual
Throw ratio	1.32 - 2.15:1
Zoom capability	Yes
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.51 - 1.99
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-24 - 24 %
Lamp power	250 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Color modes (2D)	Bright cinema, Cinema, Dynamic, Natural
Color modes (3D)	Cinema, Dynamic
Video processing	10 bit
Supported video modes	1080p
Analog signal format system	-
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Composite video in	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	32 dB
Country of origin	Philippines
Noise level (economic mode)	24 dB
RMS rated power	20 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	364 W
Power consumption (PowerSave)	279 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Bundled software	EasyMP Multi PC Projection
Pallet width	800 mm
Pallet height	2030 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet (UK)	32 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	304 mm
Width	410 mm
Height	157 mm
Weight	6900 g
Package depth	495 mm
Package width	235 mm
Package height	475 mm
Package weight	9.105 g
