Setting Options Description
IP Address Display On Selects whether to display the IP
address on the network standby
Off
screen
Parent topic: Selecting Wireless Network Settings Manually
Selecting Wireless Network Settings in Windows
Before connecting to the projector, select the correct wireless network on your computer.
1. To access your wireless utility software, double-click the network icon on the Windows taskbar.
2. Do one of the following:
If your projector is set up on an existing network (Advanced mode), select the network name
(SSID).
If your projector is configured for Quick mode, select the SSID or name you assigned to the
projector.
3. Click Connect.
Parent topic: Wireless Network Projection
Selecting Wireless Network Settings in Mac OS X
Before connecting to the projector, select the correct wireless network in Mac OS X.
1. Click the AirPort icon on the menu bar at the top of the screen.
2. Make sure AirPort is turned on, then do one of the following:
If your projector is set up on an existing network (Advanced mode), select the network name
(SSID).
If your projector is configured for Quick mode, select the SSID or name you assigned to the
projector.
Parent topic: Wireless Network Projection
Setting Up Wireless Network Security
You can set up security for your projector to use on the wireless network. Set up one of the following
security options to match the settings used on your network:
WEP encryption
51

Table of Contents

Other manuals for Epson EX5230

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EX5230 and is the answer not in the manual?

Epson EX5230 Specifications

Projection Specifications IconProjection Specifications
projection system3LCD, 3-chip technology
projection methodFront/rear/ceiling mount
pixel number786, 432 dots (1024 x 768) x 3
Brightness IconBrightness
color brightness3500 lumens
white brightness3500 lumens
contrast ratioUp to 10, 000:1
Resolution IconResolution
native resolution1024 x 768 (XGA)
resize support640 x 480 (VGA), 1024 x 768, 1152 x 864 (SXGA), 1280 x 800, 1440 x 900, 1400 x 1050 (SXGA+)
aspect ratio4:3
Lamp IconLamp
lamp type200 W UHE
lamp life (ECO mode)Up to 6000 hours
lamp life (normal mode)Up to 5000 hours
Lens IconLens
f-number1.58 – 1.72
focal length16.9 – 20.28 mm
zoom ratioDigital zoom 1.0 – 1.2
Power IconPower
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption (normal mode)283 W
power consumption (ECO mode)207 W
Operating Environment IconOperating Environment
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)37 dB
fan noise (ECO mode)29 dB
Dimensions and Weight IconDimensions and Weight
dimensions (including feet)11.6" x 9.0" x 3.1"
dimensions (excluding feet)11.6" x 9.0" x 3.0"
weight5.29 lb
