A
Document cover Blocks external light while scanning.
B
Scanner glass Place the originals.
C
Scanner unit Scans placed originals. Open when replacing ink
cartridges or removing jammed paper inside the
printer.
A
Scanner unit support Supports the scanner unit.
B
Ink cartridge holder Install the ink cartridges. Ink is ejected from the print
head nozzles underneath.
Rear
A
AC inlet Connects the power cord.
B
USB port Connects a USB cable to connect with a computer.
Part Names and Functions
>
Rear
