b. Print head / Ink cartridge holder
a. AC inlet
b. Rear cover
c. LAN port*
d. LINE port*
e. EXT. port*
f. USB port
* The availability of this part varies by product.
Guide to the Control Panel
Note:
❏ Control panel design varies depending on location.
❏ Although the control panel design and what displayed on the LCD screen such as menu names and option names may
differ from your actual product, the method of operation is the same.
User’s Guide
Getting to Know Your Product
