Continuous Paper with the Rear Push Tractor (1/2)
EPSON FX-880+/FX-1180+ Quick Guide
Continuous Paper with the Rear Push Tractor
Note:
It is recommended that you close the flap on the
front cover if paper is not loaded from the front
slot.
Follow these steps to load paper using the
rear push tractor:
1. Make sure the printer is turned off and
the tractor is installed in the rear push
p o s it i o n . A ls o m a k e s u r e t h e p a p e r g u i d e
is removed.
2. Set the paper release lever to the rear
push tractor position.
3. Release the left and right sprockets by
pulling the blue sprocket lock levers
forward.
