Epson LQ-500 - Default Settings

Default Settings
The table below shows the default conditions that become valid
when the printer is initialized.
Item Reset to:
Top of form position
Current paper position
Left and right margins Cancelled
Line spacing 1/6-inch line spacing
Vertical tab position
Cleared
Horizontal tab positions
Every eight characters
VFU channel
Channel 0
Font selection Hardware: reset to current DIP switch setting.
Software: reset to the current SelecType setting.
Character pitch Reset to current DIP switch setting.
Justification Left justification
Special printing effects
Cancelled
User-defined character set Hardware: cleared
Software: Deselected only
Graphic mode assignment ESC K = ESC * 0, ESC L = ESC * 1,
ESC Y = ESC * 2, ESC Z = ESC * 3
In addition, when the printer is initialized by turning on the power
or by an INIT signal, the data buffer is cleared of all text.
5-12 Technical Specifications
