Settings item Settings value Explanation
Select Palette
Software
*
From the following selections, choose the palette that specifies the
color and thickness of the logical pen.
❏ Software: Print according to the pen configuration set in the
application, and ignore the built-in palette of the printer.
❏ Default: Print according to the settings of the built-in palette of
the printer specified in advance. The settings of the palette
cannot be changed. The built-in palette specifies a logical pen
with a pen width of 0.35 mm and 256 colors.
❏ Palette A / Palette B: Print according to the settings of the built-in
palette that you specified for Define Palette. If Define Palette
setting is not set, the results are the same as when Default is
selected.
When Default / Palette A / Palette B are set, the pen configuration set
in the application is ignored.
Selected palette settings can be printed with Print Color Palette and
confirmed.
Default
Palette A
Palette B
Print Color Palette Print
Settings of the palette selected in Select Palette are printed as A3
size. You can check the colors corresponding to the color number for
the pen colors.
Define Palette
Palette A
Pen 0 to Pen 15
Pen Width 0.13 to 12.00 mm
In Select Palette, selecting Palette A will print in accordance with the
settings defined here.
You can define a unique built-in palette by specifying the pen width
and color for the 16 types of logical pen. Select the pen number, and
then define the pen width and pen color for each pen.
You can use Print Color Palette to print and check the colors
corresponding to the color number for the pen colors.
Pen Color 0 to 255
Palette B
Pen 0 to Pen 15
Pen Width 0.13 to 12.00 mm
In Select Palette, selecting Palette B will print in accordance with the
settings defined here.
Settings details are the same as for Palette A.
Pen Color 0 to 255
Restore default
HP-GL/2 Unique Set-
tings
No
Select Yes to restore all HP-GL/2 Unique Settings settings to the
default settings.
Yes
Thick Paper
Off
*
If the paper is thick, the print head may scuff the print surface. Choose
On to prevent scuffing. If On is set, the platen gap, which is the
distance between the print head and the paper, will widen. However,
if the platen gap is already at its maximum, then setting this to On will
have no effect.
On
Bidirectional
On
*
Setting this to On will cause the print head to print while moving both
left and right. Setting this to Off reduces ruled line misalignment, but
printing takes more time.
Off
SC-F500 Series User's Guide
Using the Menu
101
