SE Group Confidential (Related Staff Only)
Disassembly/Reassembly Overview 10
SC-P600 Revision D
1.1.2 Jigs
Note *1: The jigs above are used for adjustment (See Chapter 2 " Adjustment (p31)".) No jigs are required for disassembling/
reassembling this printer.
*2: Some of the tools listed above are commercially available.
*3: Recommended maker and model number: (If the device which can measure resistance value of 100MΩ is not used, you may
not measure a value definitely. As a result, there is the case that a parameter is not set within a standard, the Mist Recovery
Function does not act, and dirt in the printer or printing back side dirt of the paper occur.)
Oscilloscope + High-voltage probe (A high voltage probe around 100MΩ made by Tektronix: P-5210A or THDP0100)
Tester (Ex. FLUKE True-rms Multimeter 110 Series, 3+1/2 columns of DMM: More than input 10MΩ) + High voltage probe
(around 75MΩ: FLUKE 80K-6 or 80K-40)
Name
*1
Q’ty Availability
*2
EPSON Part Code
Sonic tension gauge U-508 1 --- 1640645
PF Roller Adjustment Jig 1 --- 1553098
PF Roller Adjustment Jig Stand 1 --- 1553099
Level block 1 --- 1304994
Adjustment gauge for PG adjustment 1 --- 1276333
Oscilloscope or Tester + High-voltage probe 1 O
*3
---
Calibrator (i1 Pro UV-Cut or i1Pro2) 1 O ---
To Next Page
