Epson SC-P600 Service Manual

SE Group Confidential (Related Staff Only)
Appendix Fatal Error Code 82
SC-P600 Revision D
Note "*": Not occurs except in manufacturing process.
Motor
drive time
error
Motor
drive time
error
D1H CR (PID) driving time error
• Firmware abnormal (sequence failure,
bug)
• Firmware Update
D3H PF (PID) driving time error
• Firmware abnormal (sequencefailure,
bug)
• Firmware Update
D5H ASF driving time error
D6H PUMP driving time error
• Increase of rotation load of Pump unit
(deformation of gear, misarrangement
of phase)
• Ink System
D7H APG driving time error
• Firmware abnormal (sequence failure,
bug)
• Firmware Update
D9H
Ink selector driving time
error
• Increase of changing load of ink selector
(deformation of gear)
• Ink Supply Unit
Command
error
30H
EEPROM verify error (by
command)
---
*
---
*
Printhead
system
error
40H Transistor temperature error • Main Board failure • Main board
41H
X-Hot detect error (pre
printing)
• Printhead failure
• Main Board failure
•Print Head
• Print Head FFC
• Main Board
42H
X-Hot detect error (after
flushing)
43H Head temperature error
Sequence
error
50H CR Home position error
• Paper jam
• Foreign object
• Deformation of the Main Frame
• CR lock operation failure
• Ink System
• Waste Ink Tube
51H Deadlock avoidance error
52H
Impossible contact detection
error
53H PF / ASF reset error
• detection operation of ASF phase failure
• ASF Assy
• ASF Motor
54H LD Roller reset error
55H Roll paper jam error
• Roll paper jam
• Use non-supported media (PW detector
cannot detect it)
• Mistake of the paper feed method.
• PW detector failure
• PW detector
Sensor
error
60H PW detector error • PW detector failure • PW detector
61H PW detector confusion error
• Detection operation of PW failure
(detection reflection rate)
(Printing to platen, ink mist attach to
Front Paper Guide)
• Paper jam
• Front Paper Guide Assy
• PW detector
• Remove Paper jam
62H CD tray detection error
• CD tray setting failure
• CD tray failure
• CD is not put on the tray
• PW detector failure
•CD tray
• PW detector
APG error
70H
APG assignment position
driving error
• Detection operation of ASF phase
failure
• Deterioration of PF durability
• PG Adjustment of right and left failure
•APG Assy
• Bushing Cam PG
• Bushing balancing adjustment part
71H APG reset error
Ink device
error
B0H -
CFH
Ink device error
• Ink Cartridge failure
• CSIC Terminal failure
• CR Contact Module failure
• Main Board failure
• Ink Cartridge
•CSIC
• CRCM
• Main Board
Circuit
error
80H
Circuit error
(include FFC disconnection
and fuse blowout)
• Main Board failure
• FFC disconnection
• Main Board
• FFC
Table 4-2. Fatal Error List
Error
type
Error
code
Error name Possible cause Suspect Parts
