Disassembly and Assembly
EPSON Stylus COLOR 400 Service Manual
3
-
5
3.2 Disassembly Procedures
The figure below shows procedures for disassembly.
Remove
Housing
3.2.1
Remove
Board Assemblies
3.2.2
Remove
Control Panel
3.2.3
Remove Printer
Mechanism
3.2.4
Refer to
Remove
Printhead Unit
3.2.4.1
Remove Waste
Ink Pad Tray
Assembly A
3.2.4.2
Remove Pump
Assembly and
Cap Assembly
3.2.4.3
Remove CR
Motor Assembly
3.2.4.4.
Remove PF
Motor Assembly
3.2.4.5
Remove ASF
Assembly
3.2.4.6
Remove CR
Assembly
3.2.4.7
Remove PF
Roller Assembly
3.2.4.8
Remove PE
Sensor Assembly
3.2.4.9
Remove HP
Sensor
3.2.4.10
Remove Right
and Left LD
Roller Assemblies
3.2.4.6.2
Remove Paper
Feed Roller
Assembly
3.2.4.6.1
Figure 3-1. Disassembly Flowchart
