Epson STYLUS 400 - Removing the Housing

Disassembly and Assembly
EPSON Stylus COLOR 400 Service Manual
3
-
6
3.2.1 Removing the Housing
Since the printer mechanism also acts as the lower case, you can remove the printer mechanism just by
removing the housing.
1. Open the printer cover and turn the PG adjustment lever toward the (+) side.
2. Remove 4 screws (No. 2) securing the housing, and remove the housing.
Lift up and remove the housing, pulling it toward you (to keep it from hitting the carriage).
Housing
(No. 2)
Figure 3-2. Removing the Housing
