Epson surecolor p5000 Quick Reference Guide

18 | Loading thick media in the front manual feed
Loading thick media in the front manual feed
You can load one sheet of thick paper or media between 0.8 mm and 1.5 mm thick in the front feed. For
available paper types, see the online User’s Guide.
1. Make sure the paper source setting is selected for cut sheets. Press the l button on the control panel.
Press the d button to select
Cut Sheet, then press the OK button.
2. Press the button to release the pressure roller.
3. Insert the paper with the printable side faceup over the black roller in the front manual feeder.
4. From the printer window, make sure the paper is inserted under the gray roller inside the printer.

Epson surecolor p5000 Specifications

General

Display	LCD
Product color	Black
Built-in display	Yes
Sound pressure level (printing)	47 dB
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Page description languages	ESC P
Media thickness	1.5 mm
Roll top margin	3 mm
Maximum print size	-
Power consumption (standby)	20 W
Power consumption (typical)	52 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	-20 - 40 %
Operating relative humidity (H-H)	45 - 60 %
Maximum input capacity	250 sheets
USB connector	USB Type-A
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	766 mm
Width	863 mm
Height	405 mm
