B
Select Paper Setting - Roll 1 or Roll - Remove.
Note:
You can also eject the roll paper by pressing the
Roll1 removal button.
C
Raise the spindle lock lever.
D
Remove the spindle.
E
Remove the transparent media edge guide from
the spindle.
F
Remove the roll paper from the spindle.
G
Attach the transparent media edge guide to the
spindle.
H
Place the spindle into the grooves with the
black media edge guide on the right.
I
Lower the spindle lock lever.
SC-P8500DM/SC-P8500D/SC-P6500D/SC-P6500DE/SC-P6500E/SC-T7700DM/SC-T5700DM/SC-T7700D/SC-T5700D/SC-3700D/SC-T3700DE/SC-T3700E/SC-P8500DL/SC-T7700DL Series User's Guide
Basic Operations
45
