156
Advanced Media Setting menu (in the Roll Paper menu)
Setting Options Description
Platen Gap 1.2
1.6
2.1
Adjusts the distance between the print head
and the paper; displayed when Custom
Paper is selected as the Paper Type setting
Top/Bottom Margins Standard
Top 3 mm/Bottom 3
mm
Top 15 mm/Bottom 15
mm
Top 35 mm/Bottom 15
mm
The Standard margins are as follows for the
top and bottom:
• CAD/line drawings: 3 mm
• Other: 30 mm
Select a different value as necessary.
Note: Left and right margins are always 3
mm.
Paper Suction -4 to +3 Select this to adjust the distance between the
paper and the print head. Choose lower
values for thinner papers.
Back Tension Auto
Standard
High
Extra High
Select High or Extra High if paper wrinkles
during printing
Note: If the paper still wrinkles when you
select High, select Extra High and then
change the level of suction by adjusting the
Settings > General Settings > Printer
Settings > Paper Source Settings > Roll
Paper Setup > Back Tension 2 setting.
Drying Time Drying Time per Pass Select from 0 to 10 seconds for the amount of
time the print head pauses to allow drying
after each pass
Drying Time per Page Select from 0 to 60 minutes for the amount of
time the printer pauses to allow drying after
each page is printed
