Epson SureColor T-Series - Roll 2 Unit (T7270 D;T5270 D); Roll Paper Adapter

Epson SureColor T-Series User Guide
Introduction
13
Roll 2 unit (T7270D/T5270D)
The illustration shows the T7270D.
Roll paper adapter
Use the supplied roll paper adapter when loading roll
paper onto the printer.
U“Attaching the Roll Paper Adapter” on page 27
A Paper slot
Insertion slot to feed roll paper.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
B Drawer handles
When you load or remove roll paper, hold these
handles and pull out or push in the Roll 2 unit.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
C Adapter guides
Move the roll paper adapter loaded with a roll along
these guides to attach it to the adapter holder.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
D Adapter holder
The roll paper adapter is placed in this holder after the
roll paper is attached.
E Roll lock lever
A lever that locks roll paper in place after the roll is
attached to the adapter holder.
A Adapter lock lever
Lift to unlock, lower to lock. Unlock when attaching roll
paper to the adapter, lock once the roll is attached.
B Size lever
Position according to the size of the roll core.
