Epson SureColor T-Series - Loading Roll Paper on Roll 1

Epson SureColor T-Series User’s Guide
Basic Operations
28
3
Move the size switch levers of the two supplied
roll paper adapters in accordance with the
roll-core size of the roll paper to be loaded.
4
Raise the adapter lock lever to release the lock
on each of the two roll paper adapters.
5
Attach an adapter to each end of the roll.
Press the adapters in until they are fully inserted
in the roll, with no gaps.
6
Lower the lock levers to lock the adapters in
place.
Loading Roll Paper on Roll 1
Buttons that are used in the following settings
