4USB connector (USB-A -
Device Charging)
The USB connector color is
white
Connects a USB cable for connecting to a tablet computer.
Enables data communication with the tablet while charging it.
5 Power supply connector Connects the DC cable for the AC adapter.
6 USB Type-B connector Connects the USB cable for connecting to computers.
7 Drawer kick connector Connects the modular cable for the cash drawer.
8 Status sheet button Initializes the interface settings or prints a status sheet to verify the settings.
CAUTION:
When a tablet computer is connected to the USB connector (USB-A - Device Charging), the Bluetooth function of
the printer is disabled.
To use the Bluetooth function keeping the tablet connected to the connector, disable the USB data
communication. For more details, see the Technical Reference Guide.
TM-L100 User's Manual
Part Names
9
