Epson tm-m30 User Manual

30
Chapter 3 Using the Printer Driver
3
Cash Drawer Settings
Select the [Cash Drawer Settings] tab.
The open setting for the cash drawer can be set. An open signal is sent to the cash drawer connected to the DK
connector of the printer. For the door open connector number, see the specifications of the cash drawer.
 Cash Drawer
Page [No Feed, Cut] After printing a page, cuts the paper but does not feed it.
The EPSON cash drawer is pin 2 open.
Setting Description
Does not open (Default) Does not send the drawer open command.
Open drawer #1 BEFORE printing Opens the drawer #1 before printing the text.
Open drawer #1 AFTER printing Opens the drawer #1 after printing the text.
Open drawer #2 BEFORE printing Opens the drawer #2 before printing the text.
Open drawer #2 AFTER printing Opens the drawer #2 after printing the text.
Setting Description

Epson tm-m30 Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	203 x 203 DPI
Bluetooth	Yes
USB connector	USB Type-A / USB Type-B
Standard interfaces	Bluetooth, Ethernet, NFC, USB
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Country of origin	China
Autocutter durability	1.5 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Product color	White
Power supply type	AC
Wi-Fi	No
Ethernet LAN data rates	10, 100 Mbit/s
Supported paper width	58 - 80 mm
Storage temperature (T-T)	5 - 45 °C
Operating temperature (T-T)	10 - 90 °C
Storage relative humidity (H-H)	-20 - 60 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	190 mm
Package height	230 mm
Package weight	2040 g
Quantity per pack	1 pc(s)
Pallet width	800 mm
Pallet height	2070 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Quantity per pallet layer	16 pc(s)
Quantity per pallet layer (UK)	24 pc(s)

Weight and Dimensions

Width	127 mm
