Epson TM-T88 User Manual

Setting Up the Printer 1-7
Installing or Replacing the Paper Roll
Note:
Be sure to use paper rolls that meet the specifications. Do not
use paper rolls that have the paper glued to the core because the
printer cannot detect the paper end correctly.
1. Make sure that the printer is not receiving data; otherwise, data
may be lost.
2. Open the paper roll cover by pressing the cover-open button. If
the cover-open button will not open the cover, see page 3-4 or
3-6 in Troubleshooting.
3. Remove the used paper roll core if there is one.
ERROR
POWER
PAPER
OUT
FEED

Epson TM-T88 Specifications

General

Print Method	Thermal Line Printing
Resolution	180 dpi
Auto Cutter	Yes
Printer Type	Receipt printer
Interfaces	USB, Serial, Ethernet
Paper Roll Diameter	83 mm
Power Consumption	1.8W (Standby)
Paper Width	80 mm or 58 mm (with paper width guide)
Power Supply	Internal (depending on the model) or External
