Epson TM-T88 User Manual

A-6 Dip Switch and Paper Near End Settings
Changing the DIP switch settings
If you need to change settings, follow the steps below to make your
changes:
CAUTION:
Turn off the printer while removing the DIP switch cover to
prevent an electric short, which can damage the printer.
1. Make sure the printer is turned off.
2. Remove the screw from the DIP switch cover. Then take off the
DIP switch cover, as shown in the illustration below.
3. Set the switches using a pointed tool, such as tweezers or a
small screwdriver.
4. Replace the DIP switch cover. Then secure it with the screw.
The new settings take effect when you turn on the printer.
DSW1
DSW2

Epson TM-T88 Specifications

General

Print Method	Thermal Line Printing
Resolution	180 dpi
Auto Cutter	Yes
Printer Type	Receipt printer
Interfaces	USB, Serial, Ethernet
Paper Roll Diameter	83 mm
Power Consumption	1.8W (Standby)
Paper Width	80 mm or 58 mm (with paper width guide)
Power Supply	Internal (depending on the model) or External
