Installation 1-7
Grounding the Printer
You need an appropriate ground wire to ground your printer.
Recommended wire is described below.
Thickness of wire: AWG 18 or equivalent
Diameter of terminal to be attached: 3.2
1. Make sure that the printer is turned off.
2. Connect the ground wire to the printer using the FG screw on
the back of the printer, as shown.
TM-U295
TM-U295P
To Next Page
