Commands 5-33
• When Auto Status Back (ASB) is enabled using GS a, the status
transmitted by GS r and the ASB status must be differentiated.
• If the value of
n
is out of the specified range, the printer ignores
this command.
• The status types to be transmitted are shown below:
Paper sensor status (
n
= 1, 49):
Drawer kick-out connector status (
n
= 2, 50):
Bit Off/On Hex Decimal Status for ASB
0
Off 00 0 Slip is detected by BOF sensor.
On 01 1 Slip is not detected by BOF sensor.
1
Off 00 0 Slip is detected by TOF sensor
On 02 2 Slip is not detected by TOF sensor.
2
Off 00 0 Undefined.
On 04 4 Undefined.
3
Off 00 0 Undefined.
On 08 8 Undefined.
4 Off 00 0 Not used. Fixed to Off.
5
Off 00 0 Undefined.
On 20 32 Undefined.
6
Off 00 0 Undefined.
On 40 64 Undefined.
7 Off 00 0 Not used. Fixed to Off.
Bit Off/On Hex Decimal Status for ASB
0
Off 00 0 Drawer kick-out connector pin 3 is LOW.
On 01 1 Drawer kick-out connector pin 3 is HIGH.
1
Off 00 0 Undefined.
On 02 2 Undefined.
2
Off 00 0 Undefined.
On 04 4 Undefined.
3
Off 00 0 Undefined.
On 08 8 Undefined.
