Krautkramer USN 52R/USN 52L Issue 05, 02/00 0-1

Index

1. Introduction ....................................... 1-1

1.1 Safety information ................................... 1-2

Storage batteries ....................................... 1-2

Defects/errors and exceptional stresses .... 1-2

Software .................................................... 1-3

1.2 Important notes ........................................ 1-3

Preconditions for testing with ultrasonic

flaw detectors ............................................ 1-3

Operator training ........................................ 1-4

Technical test requirements ....................... 1-4

Limits of testing ......................................... 1-5

Wall thickness measurements

with ultrasonics .......................................... 1-5

Effect of the material of the test object ...... 1-5

Effect of temperature variations ................. 1-6

Measurement of remaining wall thickness .. 1-6

Flaw boundary scanning method ................ 1-6

Echo display comparison method .............. 1-7

1.3 USN 52R/USN 52L .................................... 1-8

Special features of the two versions: ......... 1-8

1.4 Remarks on this manual.........................1-10

Before starting for the first time ................1-10

Getting to know the adjustment functions .1-10

Service .....................................................1-10

Specifications and basic settings.............. 1-10

Layout of this manual ...............................1-11

2. Standard package

and accessories ................................ 2-1

2.1 Standard package .................................... 2-3

2.2 Required accessories .............................. 2-4

2.3 Recommended accessories .................... 2-4

2.4 Recommended outside products ............ 2-5

3. Setting into operation ....................... 3-1

3.1 Positioning the USN 52R/USN 52L .......... 3-2

3.2 Power supply ........................................... 3-2

Battery operation ....................................... 3-3

Inserting the batteries ................................ 3-3

Using the battery charger ........................... 3-4
