Left Table
Left function group
GRATICULE Display graticule on/off
AMPLITUDE Amplitude reading
FREEZE MODE Storage mode
INTENSITY, Display brightness (only USN 52R)
Center function group
VELOCITY # 1 Sound velocity for coarse mode
VELOCITY # 2 Sound velocity for coarse mode
dB STEP Step range for D
GATE LOGIC Evaluation logic and on/off
Right function group
FILE NUMBER All functions are used for adjustment of
LOCATION the Data Logger in order to store and
VALUE recall the measured values.
FILE MODE
