Troubleshooting 18
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
Note *: When the optional 2nd cassette is installed for WP-5690/4630/5620/5190/5110 series.
Printer
0xF4 PF PID lock error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF driver mechanism overload (paper jam/foreign object)
• Cable disconnection
0xF8 PF load position reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
0xF9 PF load position excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing belt
0xFA PF load position excess load error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF driver mechanism overload (paper jam/foreign object)
• Cable disconnection
0xFE PF PID driving time error
• Main Board failure
0xFF PF load position driving time error
Table 1-2. Fatal Error List
Error type
Error
code
Error name Possible cause

Epson WF-5690 Series Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Fax	Yes
Functions	Print, Copy, Scan, Fax
Dimensions (W x D x H)	18.1" x 25.8" x 15.1"
Print Technology	PrecisionCore
Print Speed (Black/Color)	20 ppm / 20 ppm
Scanner Type	Flatbed, ADF
ADF Capacity	35 sheets
Display	4.3" color touchscreen
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Paper Sizes	A4, A5, A6
Ink Cartridges	Black, Cyan, Magenta, Yellow
Monthly Duty Cycle	45, 000 pages
