Disassembly/Reassembly Overview 26
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
Table 2-2. Standard Operation Time (WF-5190/5110 series)
Parts/Units
Time (second)
Pats/Units
Time (second)
Repla
ceme
nt
Adjus
tment
Total
Repla
ceme
nt
Adjus
tment
Total
Panel Unit 19 0 19 Power Supply Unit 470 52 522
Metal Plate
(Including Paper Support Assy)
80 0 80 CR Cover 319 0 319
Pickup Assy 1st
93 0 93 Ink Supply Unit Grounding Plate 345 0 345
Paper Stopper Assy
31 0 31 Ink System Supply Assy 603 1850 2453
Cover ASF Assy 10 0 10 Ink Supply Unit
559 1088 1647
Cover ASF Front
14 0 14 Printhead 554 2638 3192
Cover ASF Rear
14 0 14 Fasten Plate Center 830 0 830
Housing Rear Assy 49 0 49 Fasten Plate left 937 0 937
Housing Rear
64 0 64 Driven Pulley Assy 979 15 994
Paper Support
64 0 64 CR Motor 1028 30 1058
USB Cover
81 0 81 Maintenance Box Ink Eject Joint 639 0 639
Housing Upper
97 0 97 Ink System Unit 663 0 663
Front Housing Assy
157 0 157 Option Connecter 693 0 693
Middle Housing
305 0 305 Shaft Drive Pickup 811 0 811
Stacker Assy
169 0 169 ASF Drive Change Lever Assy 701 0 701
Main Board Unit 589 890 1479 ASF Drive Change Lever Holder 703 0 703
Main Board Cable Holder 601 0 601 Spur Gear 11.2 703 0 703
Shield Plate Holder 636 0 636 Extension Spring 0.63 703 0 703
Main Board Shield Plate 818 0 818 Spur Gear 11.2 703 0 703
Main Board
Read OK 862 119 981 Compound Gear 16,10.4 703 0 703
Read NG 862 890 1752 CR Scale/Extension Spring 2.03
1076 0 1076
Main Board Shield Plate Lower 862 0 862 Front Frame Assy 1189 613 1802
Wi-Fi Board
327 0 327 Star Wheel Assy 1111 99 1210
Rear ASF Assy
379 134 513 EJ Roller 1227 366 1593
Rear ASF Guide Upper Assy
416 0 416 Frame Base Assy 1287 1678 2965
CSIC FFC
352 0 352 Main Frame Mounting plate 1312 0 1312
Metal Plate Left 379 0 379 Support Plate Right/Left 1343 250 1593
PF Encoder 393 0 393
CR Guide Frame Assy
(Including Carriage Assy)
1731 878 2609
PF Encoder FFC 406 0 406 CR Guide Frame 1739 748 2609
PF Tension Stopper Holder 410 15 425 Carriage Assy
1739 1524 3263
PF Timing Belt 425 15 440 Main Frame Assy 1981 1583 3564
Decompress pump Unit
424 0 424 Paper Guide Upper Assy 2089 463 2552
PE Lever Holder Assy 2089 56 2095

Epson WF-5690 Series Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Fax	Yes
Functions	Print, Copy, Scan, Fax
Dimensions (W x D x H)	18.1" x 25.8" x 15.1"
Print Technology	PrecisionCore
Print Speed (Black/Color)	20 ppm / 20 ppm
Scanner Type	Flatbed, ADF
ADF Capacity	35 sheets
Display	4.3" color touchscreen
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Paper Sizes	A4, A5, A6
Ink Cartridges	Black, Cyan, Magenta, Yellow
Monthly Duty Cycle	45, 000 pages
