Adjustment Details of Adjustments 61
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
2. Start the Printer inspection mode by turning the product on with holding down the [Home] button,
[*]button, [Stop] button and [Power] button on the panel simultaneously.
Figure 3-5. Preparation of the Head Angular Adjustment (2)
3. On the displayed menu screen, select “1. Mechanism Inspection” and press the [Color] button.
Figure 3-6. Preparation of the Head Angular Adjustment (3)
4. On the displayed menu screen, select “1. Printer Inspection Mode” and the press the [Color] button.
Figure 3-7. Preparation of the Head Angular Adjustment (4)
5. When following message is displayed, Head Angular Adjustment can be performed.
Figure 3-8. Preparation of the Head Angular Adjustment (5)
Stop button* buttonHome buttonPower but on
Run:Color / Select:[3][6]
1. Mechanism Inspection
2. Special Inspection
3. FAX Inspection
4. Touch Screen Inspection
5. Development Mode
6. FAX Development Mode
7. Normal Mode
Run:Color / Select:[3][6]
1. Printer Inspection mode
2. SCN/ADF FT Mode
3. SCN Endurance Mode
4. ADF Endurance mode
Printer Inspection Mode
