Appendix 18
Epson WF-7620 / WF-7610 / WF-7110 Series Revision B
Printer
0xD6 ASF PID excess torque limitation error
Pickup Roller (2nd cassette) drive mechanism overload (paper jam/foreign
object)
0xD8 ASF load position reverse error
• ASF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Paper jam
0xD9 ASF load position excess speed error
• ASF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Motor driver failure (Main Board failure)
0xDA ASF load position excess load error
• ASF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• ASF Motor failure
• Pickup Roller (2nd cassette) drive mechanism overload (paper jam/
foreign object)
• Cable disconnection
0xDE ASF PID driving time error
• Main Board failure
0xDF ASF load position driving time error
0xE1 CR PID excess load error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xE2 CR PID excess speed error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
0xE3 CR PID reverse error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE4 CR PID lock error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xE5 CR PID speed fall error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE8 CR load position reverse error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE9 CR load position excess speed error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
0xEA CR load position excess load error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xEB APG driving time error • Main Board failure
0xEC APG excess speed error
• APG Sensor failure
• APG Motor failure
• Tooth skip of APG drive gear
Table 1-2. Fatal Error List (Printer)
Error type
Error
code
Error name Possible cause
