Note "*": Not occurs except in manufacturing process.
Printer
0xEE CR PID driving time error
• Main Board failure
0xEF CR load position driving time error
0xF1 PF PID excess load error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xF2 PF PID excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
0xF3 PF PID reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
• Paper jam
0xF4 PF PID lock error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xF6 PF PID excess torque limitation error ---
*
0xF8 PF load position reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
0xF9 PF load position excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
0xFA PF load position excess load error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xFE PF PID driving time error
• Main Board failure
0xFF PF load position driving time error
Table 1-2. Fatal Error List (Printer)
