Part index
The index below refers to Fig. 1 on page 4.
1. Air cap adjusting cover
a) Slot* (x2)
2. Union nut
3. Air cap
a) Anchor (x2)
b) Spigot (x2)
4. Spray nozzle (Ø 2.5mm)
a) Nozzle hole
b) Notch
c) Lower step
d) Higher step
5. Nozzle needle
6. Spray head
a) Spigot
7. Air ow adjustment lever
8. Switch Trigger
a) Fluid adjusting knob
9. Container holder attachment point
a) Indication mark*
b) Slot* (x2)
10. Handle front attachment point
a) Pin* (x2)
11. Air inlet attachment point
a) Slot* (x2)
b) Indication arrow*
12. Hose connector (x2)
a) Pin* (x2)
13. Air hose
14. Compartment for spray gun
15. Lower extension
a) Locking pin
16. Upper extension
17. Transport handle
a) Lock button
18. Rotatable On/Off switch
a) Indication line*
19. Air outlet attachment point
a) Slot* (x2)
b) Indication arrow*
20. Air hose bracket (x2)
a) Wheel compartment* (x4)
b) Cord holder* (x2)
21. Power cord with plug
a) Cord clip
22. Front wheel (x2)
a) Latch* (x2)
23. Air vents
a) Air lter*
b) Air lter cover*
c) Latch* (x3)
24. Rear wheel (x2)
a) Latch* (x2)
b) brake*
25. Handle
26. Lock catch
27. Paint container
a) Suction tube
b) Quick ll cap
c) Holder hook
d) Check valve
i) Top sleeve
ii) Rubber seal
iii) Spring
iv) Middle Sleeve
v) Valve extension
e) Seal ring
f) Seal pad
28. Paint dipstick
a) Hook
b) Paint level marking
29. Viscosity measuring cup
30. Spray nozzle (Ø 1.8 mm)
31. Cleaning needle (with protector)
32. Cleaning brush
