ergoline AFFINITY 660 DYNAMIC POWER - 5.7 Cleaning and maintenance work preparation

Cleaning and maintenance
40
5.7 Cleaning and maintenance work
preparation
5.7.1 Lift up the acrylic glass panel and the
partition
– Remove the screws.
– Lift up the acrylic glass panel.
– Lift up the supports and prop the acrylic glass panel on them.
WARNING!
Risk of scratching!
Use the recesses provided on the acrylic glass panel.
– Lift up the partition (only for devices with an air conditioning unit).
– Fold out the supports.
– Prop the partition on the supports.
The assembly is the same process in reverse order.
When assembling please note:
– Remove fingerprints and other soiling carefully.
