ergoline AFFINITY 700 ADVANCED PERFORMANCE - Cleaning or Replacing the UV Lamps in the Side Section; Cleaning or Replacing UV Lamps and Filter Panels in the Canopy

Cleaning and maintenance
58/84
4.10 Cleaning or replacing the UV lamps in
the side section
– Removing the side section panel: see page 50.
Replacing lamps:
UV low pressure lamps: see page 54.
UV high pressure lamps and filter panels: see page 56.
When assembling the device please note:
– Re-lock the locks.
4.11 Cleaning or replacing UV lamps and
filter panels in the canopy
– Removing the canopy panel: see page 49.
– Remove the screws and then remove the lamp cover.
The following components listed in the maintenance plan are fitted in the
canopy:
Replacing lamps:
UV low pressure lamps: see page 54.
UV high pressure lamps and filter panels: see page 56.
 Facial tanner filter panels
 Facial tanner UV low pressure lamps and the associated starters
