Radio Configurations, RBS 2106 and RBS 2206
Basic Configuration F9det_2.4 and F18dt_2.4
TX1
RX1
RX2
TX2
TX1
dTRU
TX1
TX2
TX1
TX2
RX1
dTRU
CDU-F
DPX
FCOMB
FCOMB
RX2
TX2
CXU
RX1
RX2
LNA
LNA
TX/
RXA
Ant.
P007377A
X
DPX
DPX
LNA
X
DPX
DPX
LNA
RXB
Figure 8 F9det_2.4 and F18dt_2.4
Characteristics
Number of CDUs 1
Frequency band E-GSM (F9det_2.4)
GSM 1800 (F18dt_2.4)
Max. number of TRXs 4
Number of feeders 2
Number of antennas 2
Antenna configuration TX/RX + RX
TMA configuration ddTMA + ddTMA or
ddTMA + rTMA
40 (485)
