2 INTRODUCTION
Feed 402 is a wire feed unit intended for MIG/MAG & FCAW welding when coupled with a Mig
500i power source.
They can be used with wire bobbins up to Ø300mm
ESAB’s accessories for the product can be found on page 13.
2.1 Equipment
The Feed 402 wire feed unit is supplied with
● Instruction manual
● One pressure roller
● Two feed rollers (one Ø1.2/1.6mm V-groove & one Ø1.2/1.6mm Knurled V-groove)
3 TECHNICAL DATA
Feed 402
Power supply
Power requirement
Motor current I
max
Setting range
Wire feed speed
Gun connection
Max. diameter wire bobbin
Wire dimension
Weight
Dimensions lxwxh
Operating temperature
Transportation temperature
Shielding gas
Max pressure
Permissible load at
60% duty cycle
Enclosure class
24 V DC
120 VA
5 A
1.5 - 20.0 m/min
EURO
300 mm
0.8 - 1.6 mm
9 kg
460 x 210 x 330 mm
-10 to +40°C
-20 to +55°C
All types intended for MIG/MAG welding
8 bar
500 A
IP21
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld at a
certain load without overloading. The duty cycle is valid for temperatures up to 40°C
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration by solid
objects or water. Equipment marked IP21 is designed for indoor use.
