ESAB EM235ic - Technical Data; Technical Specifications

3 TECHNICAL DATA
0463 479 001
- 13 -
© ESAB AB 2017
EM series
• ESAB EM235ic power source
• Tweco® Spray Master 250A MIG gun with 15ft (4.5m) cable, 0.030in., 0.035in.,
0.045in. (0.8mm, 0.9mm, 1.2mm) contact tips and Allen Key
• Ground clamp, 10ft (3m), 250A
• Input cable 10ft (3m) with 230V plug (part of power source)
• Power adapter cable (230V to 120V, 15A)
• Victor® Flow Meter with 10ft (3m) gas hose
• ESAB OK AristoRod™ premium solid wire 0.035in. (0.9mm) 11# spool
• ESAB Atom Arc Acclaim 1/8in. premium stick electrodes 1# sample pack
• Guide tubes 0.023in. – 0.045 in. (0.6mm – 1.2mm)
• Thickness gauge tool
• USB stick including manuals
• Safety manual
• Quick start guide
3 TECHNICAL DATA
EMP235ic
Voltage 230V, 1 ~ 50/60Hz 120V, 1 ~ 50/60Hz
Primary current
I
max.
GMAW - MIG
32.1A
Breaker 20A: 28.6A
Breaker 15A: 20.3A
I
max.
GTAW - TIG
26.1A Breaker 15A: 20.8A
I
max.
SMAW - Stick
31.3A Breaker 15A: 20.8A
I
eff.
GMAW - MIG
20.31A
Breaker 20A: 18.0A
Breaker 15A: 14.6A
I
eff.
GTAW - TIG
19.8A Breaker 15A: 14.7A
I
eff.
SMAW - Stick
16.5A Breaker 15A: 14.7A
Permissible load at GMAW - MIG
100% duty cycle 160A/22.0V Breaker 15A: 75A/17.75V
Breaker 20A: 90A/18.5V
60% duty cycle 200A/24.0V Breaker 15A: 90A/18.5V
Breaker 20A: 110A/19.5V
40% duty cycle 235A/25.75V Breaker 15A: 100A/19V
20% duty cycle – Breaker 20A: 130A/20.5V
Setting range (DC) 15A/14.75V –
250A/30.0V
15A/14.75V –
130A/20.5V
Permissible load at GTAW - TIG
100% duty cycle 170A/16.8V 100A/14V
60% duty cycle 215A/18.6V 120A/14.8V
40% duty cycle – 130 A/15.2V
30% duty cycle 240A/19.6V –
Setting range (DC) 5 A/10.2V – 240A/19.6V 5 A/10.2V – 200A/18.0V
