ESAB FABRICATOR 252i
INTRODUCTION 2-4 Manual 0-5423
2.09 Specifications
Description
Fabricator 252i MULTI PROCESS
WELDING INVERTER
Power Source Dimensions H 17.5" x W 10.25" x D 23.5"
Power Source Mass 65 lbs.
Cooling Fan Cooled
Welder Type Multi Process Power Source
Standard IEC60974.1
Number of Phases Single Phase
Nominal Supply Voltage 208/230 VAC ± 15%
Supply Voltage Range 187 - 265 VAC
Nominal Supply Frequency 50/60Hz
Open Circuit Voltage 72 VDC
MIG Voltage Range 14-30 VDC
Wirefeeder Speed Range 67 - 700 ipm (1.7 - 17.8 M/min.)
Protection Class IP23S
Supply Lead & Plug Rating 50 Amps (10 AWG)
Welding Current Range (MIG Mode) 20-300 Amps
Welding Current Range (LIFT TIG Mode) 5-300 Amps
Welding Current Range (STICK Mode) 20-230 Amps
Effective Input Current (I1eff) 22.4 Amps
Maximum Input Current (I1max) 34.7 Amps
Single Phase Generator Requirement 10 kVA
MIG (GMAW) Welding Output, 40°C, 10 min. 250A @ 40%,26.5V
200A @ 60%, 24V
150A @ 100%, 21.5V
STICK (SMAW) Welding Output, 40°C, 10 min. 230A @ 40%,29.2V
200A @ 60%, 28V
150A @ 100%, 26V
TIG (GTAW) Welding Output, 40°C, 10 min. 250A @ 40%,20V
200A @ 60%, 18V
150A @ 100%, 16V
Table 2-1: Fabricator 252i Specification
NOTE!
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all
capacities, measurements, dimensions and weights quoted are approximate only. Achievable capacities
and ratings in use and operation will depend upon correct installation, use, applications, maintenance and
service.
