ESAB Fabricator EM 400i User Manual

3 TECHNICAL DATA
0446 404 001
- 7 -
© ESAB AB 2020
3 TECHNICAL DATA
FabricatorEM400i
Mains voltage 380-440V ±10%, 3~50/60Hz
Primary current I
max
380V 400V 415V 440V
MIG/MAG 24 A 23A 22A 21A
MMA 25 A 24A 23A 22A
Setting range (DC)
MIG/MAG 30A/12.0V-400A/34.0V
MMA 30A/21.2 V-400A/36.0V
Permissible load at MIG/MAG
60% duty cycle 400 A/34.0 V
100% duty cycle 310 A/29.5 V
Permissible load at MMA
60% duty cycle 400 A/36.0 V
100% duty cycle 310 A/32.4 V
Power factor at maximum current 0.93
Maximum input power at idle mode <50W
Efficiency at maximum current 87%
Open-circuit voltage 63.7V
Operating temperature -10 to +40°C
Transportation temperature -20 to +55°C
Dimensions l × w × h 712 × 325 × 470mm (28.1 × 12.8 × 18.5 in.)
Weight 59 kg (130 lb.)
Insulation class H
Enclosure class IP 23S
Application class
FabricatorEM500i
Mains voltage 380-440V ±10%, 3~50/60Hz
Primary current I
max
380V 400V 415V 440V
MIG/MAG 34 A 33A 31A 30A
MMA 35 A 34A 32A 30A
Setting range (DC)
MIG/MAG 30A/15.5V-500A/39.0V
MMA 30A/21.2 V-500A/40.0V
Permissible load at MIG/MAG
60% duty cycle 500 A/39.0 V
100% duty cycle 390 A/33.5 V
Permissible load at MMA
60% duty cycle 500 A/40.0 V

ESAB Fabricator EM 400i Specifications

General

Brand	ESAB
Model	Fabricator EM 400i
Category	Welding System
Language	English
