18
MigMaster Spare Parts List - Spare parts should be ordered from your nearest ESAB supplier.
When ordering, indicate model, serial number, description and part number according to the spare parts list.
Description Part No. Symbol
1 Platform 0367204003
2 Rubber mat 0320539006
3 Upper Right Side Panel 0558002420
4 Lower Right Side Panel 0558002421
5 Rubber Wheel (2 Req’d) 0229206402
6 R-Pin Locking (2 Req’d) 0558002422
7 Swivel castor (2 Req’d) 0369729001
8 OKC-50 Cable connector 0160362881
9 Front panel with text 0558002423
10 Indicator lamp (temp) 0369733001 K38
11 Switch (on/off) 0193317004 K5
12 Knob (voltage) 0318113003
13 Knob (timers) 0466175001
14 Left Side panel with text 0558002424
15 Knob (wire feed) 0466175002
16 Fixing handle (right) 0369559001
17 Fixing handle (left) 0369559002
18 Pipe handle 0369567002
Item
No.
MigMaster Spare Parts List (Figure 5)
Note: To replace entire Reverse Polarity 0558002432
