5 OPERATION
0463 691 001
- 28 -
© ESAB AB 2019
5.14.2 Wire feed unit in vertical position
5.14.3 Wire feed unit in horizontal position
NOTE!
In order to attach the wire feeder to the wheel kit in the horizontal position, the two
bumpers on the wire feeder door must be removed.
