4 INSTALLATION
0463 732 001
- 13 -
© ESAB AB 2020
Recommended fuse sizes and minimum cable area for the Rogue ES 150i, ES 180i
Supply voltage 230VAC
Maximum recommended extension cord
length 100m(328ft)
Minimum recommended extension cord size 4mm
2
NOTE!
Different variants of Rogue ES 150i, ES 180i are certified for different outlet
voltages. Always refer to the rating plate for the specification of the power source in
use.
NOTE!
Use the power source in accordance with the relevant national regulations.
Supply from power generators
The power source can be supplied from different types of generators. However, some
generators may not provide sufficient power for the welding power source to operate
correctly. Generators with Automatic Voltage Regulation (AVR) or with equivalent or better
type of regulation, with rated power 8 kW, are recommended.
