Polymerase Chain Reaction Cabinets
Distance from walls = a (mm) (in)
Distance apart = x (mm) (in)
Distance from walls = b (mm) (in)
Distance apart = y (mm) (in)
Average Count: for particle size of 0.5 micron and larger sampled in 0.028
m
3
of air
Cleanliness rating: ISO Class 3 as per ISO 14644.1 (≤ 35 count for particles equal to and larger
than 0.5 µm per 1 m
3
or 35.3 ft
3
of air).
Results: Pass / Fail
1.3.1.4
Light Intensity Test
A light intensity meter was used to measure light intensity at work surface level of the cabinet:
Note: The particle count done in the factory is “as-built” condition. If 0.5 micron
counter is used on the field, there shall be no more than 35 particles of 0.5 μm
sampled in 1 m
3
(35.3 ft
3
) of air to reach ISO Class 3.
