Appendix 235
FX Amounts
The Effects Amount controls the percentage of effected (wet) signal to
un-effected (dry) signal. This function would be analogous to the effects
return on a mixing console. The effects amount for each of the four
stereo submix outputs can be individually controlled.
1. Press the Preset Definition key. The LED will illuminate and the
Preset Definition menu will appear.
2. Select Effects (9). The main Effect screen will appear.
3. Select Preset Effect A or B as desired (0 or 1).
4. Press the Right Cursor key twice to access the Sends screen. The
Effect Send screen will appear..
PRESET EFFECT B
Sends:
Main: 10% Sub1: 30%
Sub2: 20% Sub3: 40%
5. Adjust the Effect Sends as desired.
6. Press the Preset Definition key to return to the main menu.
