Operating Evoke/Evoke KP
Calling:
Press the call button to call the indoor monitor.
The speaker of the indoor monitor sounds and
the indicator light flashes.
Talking/listening
Pick up the handset to talk with the visitor.
Pick up the handset to listen to the outside or
talk to the outside door station
Replace the handset to end the call.
Unlocking:
Press the button to unlock the door
Extension call transfering:
To transfer an incoming call to another handset
press this will call all other handsets
on the system.
Evoke KP Programming
Default Programming Code: 1234
Before the keypad will work to open the
door a user pin will be needed to be
programmed in to the system.
Enter the programming mode
1. Press
*
“bleep” should be heard twice, then
enter the 4-digit programming PIN number,
“b
leep” should be heard three times with LED
light flashing. This indicates that entry to the
programming mode has been successful.
2. Press
*
to exit the programming mode the
“bleep” will sound five times.
Add user PIN numbers
1. Enter the programming mode first.
2. Enter 01 - 40 (location 31 - 40 are for latching
PIN numbers only).
3. Enter the new 4 digit PIN number, if
successful the “bleep” will sound three times.
If when entering the new 4 digit PIN number a
long “bleep” is heard twice, this indicates that
this number is already in use on the system.
The keypad will now return to the
programming mode.
Delete user PIN numbers
1. Enter the programming mode first.
2. Enter the allocation number you want to
delete from 01 - 40.
3. Press # to delete the PIN number stored
allocation number 01- 40.
4. After “bleep” is heard three times, this
confirms PIN number has been deleted and
returns to the programming mode.
Delete user PIN numbers directly
1. Enter to the programming mode first.
2. Press #. After “bleep” is heard twice, then
enter the 4-digit PIN number for deletion.
3. After “bleep” is heard three times, this
confirms PIN number has been deleted and
returns to the programming mode.
Delete all settings
1. Enter the programming mode first.
2. Press #. After “bleep” is heard twice, press #
again. Another “bleep” is heard twice.
3. Then, press # for a further seven times, the
system deletes all the setting. The unlocked
time changes to 1 second, and the
programming PIN number does not change.
After hearing “bleep” for five times, the
system is now reset, and all the user PIN
numbers are deleted.
Set unlocked time
Factory default setting is 5 seconds.
1. Enter the programming mode first.
2. Enter code 00, and the “bleep” should be heard
twice.
3. Enter the unlocked time: 2 digits (01 - 99
seconds); 00 is not valid in this mode.
4. After “bleep” is heard for three times, it will
return to the programming mode.
5. Press
*
to exit the programming mode.
Set programming code
1. Switch off the power, press
*
and hold,
switch on t
he power. After hearing a long
“bleep”, release
*
.
2. After the long “bleep” stops, another “bleep” is
heard, now you can enter the new 4-digit
programming PIN number.
3. After entering the new PIN number, a “bleep”
will be heard for 5 times.
Telephone: 01527 515150 www.espuk.com
