ESP FHDV 4 R - DVR Connection Diagram

4
DVR CONNECTION DIAGRAM
Notes on Camera Connection:
The DVR is specifically designed for High Definition cameras using AHD technology.
The DVR can also support standard definition cameras.
Monitor
DVR rear panel
VGA / HDMI
Connection
Mouse controller
Local area
network
Power supply / Splitter lead
Video / Power cable
Video Input
(BNC female)
BNC Video (female)
Power Jack (female)
Camera
