MAG816 - Installation and Operation Manual 31

MAG816 Spare Parts Kit

1. Resistor 10K ±1%, 0,25W 2

2. Anchors 6х30mm 4

3. Fuse 2А, T-Type 5x20mm 1

4. Self tapping screw М4,2х35 cross slot DIN7981 4

5. Jumper 2

6. Cable tie 2,5/160mm 2

7. Lightpipe for indication 5

8. EOL - module 2

9. Plastic cap 21

4-Zone Expander MAG816 Spare Parts Kit

10. Screw М3х6 DIN7985 4

11. Lightpipe for indication 1

12. EOL - module 4

13. Jumper 1

4-Sounder Expander MAG816 Spare Parts Kit

14. Screw М3х6 DIN7985 4

15. Lightpipe for indication 1

16. Resistor 10K ±1%, 0,25W 4

Hanger for Flush Mounting Spare Parts Kit

17. Screw М4х40 cross slot DIN7985 4

18. Washer М4 DIN522 4

19. Screw М4х30 cross slot DIN965 2

20. Hanger for ush mounting, 300x41x18mm 2
