Estun E10 User Manual

E10 Operation Manual V1.15
PAN31 Outputs definition 1
PAN32 X-axis reference point searching set 0
PAN33 X-axis reference point value 0
PAN34 IN1 level mode 0
PAN35 IN2 level mode 0
PAN36 OUT1 level mode 1
PAN37 OUT2 level mode 1
PAN38 OUT3 level mode 1
PAN39 OUT4 level mode 1
PAN40 OUT1 function mode 0
PAN41 OUT2 function mode 0
PAN42 OUT3 function mode 0
PAN43 OUT4 function mode 0
PAN44 RLY1 function mode 1
PAN45 RLY2 function mode 2
PAN46 RLY3 function mode 0
PAN47 Counting direction 0
Since the difference between shearing machine and press-braking machine only lies in the parameter
numbers while the meanings, units, default values are all the same. So we only illustrate the parameters of
the press-braking machine in details.
PAN 01. Decimal point of X- axis
Range ：0 - 4
Unit：None
Default：1
Description： Used to fix the position of decimal point of the numbers displayed
PAN 02. Decimal point of Y- axis
Range ：0 - 4
Unit：None
Default：2
Description： Used to fix the position of decimal point of the numbers displayed
PAN 03. Multiple factor on X-axis
Range ：1 - 9999
Unit：None
Default：4
Description: controller accepts pulse signals from the external and displayed in mm. This
requires a switching process, which explains why the multiple factor and dividing factor exist.
Multiple factor = number of encoder wires × multiple frequency constant of encoder ×
display resolution.
The display resolution is relative with the decimal point position. If it is not a decimal
number, then the resolution is 1; if it has one digit after decimal point, then the resolution is 0.01;
if it has two digits after decimal points, then the resolution is 0.001.
Multiple frequency constant of encoder: the constant in the decode circuit, its value is
always 4.
Number of encoder wires: decided by the encoder.
PAN 04. Y -axis multiple factor
Range ：1 - 9999
