E10 Operation Manual V1.15
Unit：None
Default：4
Description: the same as PAN 03
PAN 05. X-axis dividing factor
Range ：1 - 9999
Unit：None
Default：1
Description: dividing factor = screw rod pitch × deceleration ratio between encoder and transfer
screw rod.
F = multiple factor / dividing factor.
That is to say, F is used to display the unit plus one, the number of pulse generated from
Encoder. Deceleration ratio between encoder and transfer screw rod: the encoder cycle numbers
when the transfer screw rod cycles once.
MM:
Multiple frequency constant = 4
Resolution = 0.1
Screw rod pitch = 10mm
Deceleration ratio between encoder and transfer screw rod = 1
That is F = 100 × 4 × 0.1 / 10 = 4 /1
Enter multiple factor 4, dividing factor 1; every 4 pulse represent one displayed unit
（0.1mm）
PAN 06. Y-axis dividing factor
Range ：1 - 9999
Unit：None
Default：1
Description ：the same as PAN 05
PAN 07. Screw rod pitch of X -axis
Range ：0 - 99999
Unit：Display Unit
Default：0
Description ： There are some gaps between screw rods, as for X axis, when the system is
working, if the alarm for one-side positioning not done will be triggered is decided by the
existence of gap and the distance of the gap.
PAN 08. Screw rod pitch of Y -axis
Range ：0 - 99999
Unit : display Unit
Default：0
Description ： There are some gaps between screw rods. As for Y-axis, when gap exists, it could
be compensated to avoid fault and position more accurately
PAN 09. X -axis counter direction
Range ：0 - 1
Unit：None
Default：1
Description: 0: Minus
1: plus
PAN 10. Y-axis counter direction
Range ：0 - 1
Unit：None
Default：1
Description: 0: Minus
1: plus
PAN 11. X-axis min position
Range ：0 - 999999
Unit：
Display Unit
