E10 Operation Manual V1.15
Default：5.0
Description ：X-axis min position。
PAN 29. X-axis max position
Range ：0 - 999999
Unit：Displays Unit
Default：6000.0
Description ：X-axis max position
PAN 31. Y-axis min position
Range ：0 - 999999
Unit：Display Unit
Default：5.00
Description ：Y-axis min position
PAN 49. Y-axis max position
Range ：0 - 999999
Unit：Display Unit
Default：600.0
Description ：Y-axis max position
PAN 56. recover the default value
Range ：0 - 1
Unit：None
Default：0
Description ：When the parameter is 0, it is not effective. When the parameter is set as ‘1’, all the
parameters will recover to the default value.
PAN57. Outputs definition
Range ：0 - 1
Unit：
Default：1
Description ：It is suggest not to edit .
PAN58. X-axis reference point searching set
Range :0-1
Unit: None
Default: 0
Description: The function of searching for X-axis reference point is available when the value of
this parameter sets as ‘1’.
Note: When setting the value of this parameter as ‘1’, be sure to modify the location of
reference points.
PAN 59. X-axis reference point value
Range: 0 - 999999
Units: Display unit
Default: 0
Description: When the function of searching for X-axis reference point is available, the
parameter sets the value as a reference point.
PAN60. Y-axis reference point searching set
Range: 0-1
Unit: None
Default: 0
Description: The function of searching for Y-axis reference point is available when the value of
this parameter sets as ‘1’.
Note: When setting the value of this parameter as ‘1’, be sure to modify the location of
reference points.
PAN 61. Y-axis reference point value
Range: 0 - 999999
Units: Display unit
Default: 0
Page 21 of 28
