Etac Molift User Manual

BM04101 Molift Quick Raiser English - Rev F 09/2012 Page 1 of 20

Etac Molift Specifications

General

Category	Medical Equipment
Type	Patient Lift
Battery Life	Up to 50 lifts per charge
Lifting Range	370-1795 mm (14.6-70.7 in)
Weight	36 kg (79 lbs)

Summary

About Molift Quick Raiser 1, 2 and 2+

Before using the patient lifter

Operator must be trained. Practice lifting, know how to move others, and use correct slings and accessories.

Molift Quick Raiser - Use

Check list before use

Verify lifter has no damages, loose parts. Check emergency stop, battery and service lamps are functional.

General Safety Precautions

Lift and Transferring

Consider factors during transferring, stand to side, ensure limbs are clear, maintain eye contact for user comfort.

Adjusting and Transferring

Using a V-shaped arm

Fasten sling, pull ropes firmly into locks. Patient should grab handlebars. Ropes lock tighter with patient weight.

Using a U-shaped arm

Attach ropes to lifting arm by pulling them firmly from above into rope locks.

Movement

Patient shouldn't stand straight up. Avoid furniture, walls, sloping surfaces, obstacles. Pull over sills with big wheels first.

Lowering

Lower patient to desired position. Lock wheelchair brakes, not lifter. Release strap, remove sling.

Assembly and Disassembly

Unpacking

Verify box for damage. Check contents: chassis, column, knee support, lifting arm, drive handle, hand control, battery, charger.

Assembly

Assemble knee pad bracket, slide driving handle, guide hand control wire. Ensure column and bolts are secured.

Attach the Lifting Arm

Attach arm to trolley using safety lock (QR1/QR2) or bolt/screws (QR2+). Verify correct attachment.

Checklist

Verify arm fastened, column placed correctly and secured. Ensure no damage or cracks before use.

Disassembly

Remove battery, lifting arm, drive handle, knee support. Loosen column bolts and lift out column.

Storage

Remove battery, activate emergency stop for long storage. Store within specified pressure, humidity, and temperature.

Battery and Charging

Battery Care and Charging

Charge battery when needed. New batteries need full charge/discharge cycles. Battery has ~500 charge cycles.

Electrical System

Service lamp signals need for service. Green light means ready. No light means push button to activate.

Safety Devices

Emergency Stop and Emergency Lowering

Emergency stop cuts power. Manual/electrical lowering available. Electrical lowering disabled by emergency stop.

Technical Data Molift Quick Raiser 1

Technical Data Molift Quick Raiser 2

Technical Data Molift Quick Raiser 2+

Labels and Symbols

Explanation of Symbols Used in this Manual

Symbols indicate safety warnings (injury risk) or important information (efficiency, routines, facts).

Safety Control Label

Label for periodic inspection. Space for calendar and signed label from service partners.

Accessories

Molift Easy Raiser Lifting Strap

Available in sizes XS to XL. Part numbers listed for different sizes.

Quick Raiser Sandals

Available in sizes Small, Medium, and Large. Part numbers provided for each size.

Sling Size Guide

Guide for selecting sling size based on weight and waist measurements, with colour codes.

Lifting Arms

Details on V-shape and U-shape arm assemblies, including part numbers and SWL.

Troubleshooting

Maintenance

Cleaning

Use pH-neutral detergents. Avoid solvents, strong liquids. Disinfect with isopropyl alcohol. Clean with damp cloth.

Monthly Maintenance

Check for loose parts, rotate castors, verify contacts/cables. Clean contacts. Run lifter to verify function.

Periodic Inspection

Annual inspection by authorized personnel. Checklist to be filled and signed. Owner responsible for keeping records.

Service

Service lamp signals need for service (yellow/red light). Contact service representative. Audible alarm for immediate service.

Checklist for Periodic Inspection

Compulsory Safety Check (Annual)

Visual inspection for damage, proper assembly, and accessories. Function checks for emergency stop, movement, and controls.

Servicing Required

Indicates if servicing is unnecessary (green lamp, unit <5 years old) or required.

Compulsory in Case of Faults

Procedure for faults: remove from service, mark 'OUT OF ORDER', summon certified personnel for repairs.

Compulsory Where Lifter Checked and Approved

Lifter passed check, affixed with safety label, dated, signed. Checklist and copy sent to client and dealer.
